Heavy Duty Lathe Machine
Product Details:
X
Product Description
Keeping track with the latest developments in the market, we manufacture, export and supply a broad collection of Heavy Duty Lathe Machine. This heavy duty lathe machine is highly demanded in both, national and international markets due to its sturdy construction, durability, user friendliness and reliable functionality. The Heavy Duty Lathe Machine is manufactured using the highest quality raw materials and sophisticated machines in adherence with the set industry standards.
Technical Specifications:
| Particulars | Model-1 | Model-2 | Model-3 | Model-4 | Model-5 |
| Length of Bed | 5'6" (1676) | 7' (2134) | 9' (2743) | 10' (3048) | 12' (3658) |
| Height of Center | 10' (250) | 10' (250) | 10' (250) | 10' (250) | 10' (250) |
| Maxi. Swing over Bed | 18' (450) | 18' (450) | 18' (450) | 18' (450) | 18' (450) |
| Maxi. Swing over Carraige | 10' (255) | 10' (255) | 10' (255) | 10' (255) | 10' (255) |
| Admit between centres | 20' (508) | 38' (965) | 62' (1574) | 74' (1880) | 98' (2490) |
| Width of Bed | 12.3/4' (323) | 12.3/4' (323) | 12.3/4' (323) | 12.3/4' (323) | 12.3/4' (323) |
| Length of gap | 12' (305) | 12' (305) | 12' (305) | 12' (305) | 12' (305) |
| Length of gap infront of faceplate | 8' (203) | 8' (203) | 8' (203) | 8' (203) | 8' (203) |
| Dia. of 6TPI spindle nose | 3' (76) | 3' (76) | 3' (76) | 3' (76) | 3' (76) |
| Spindle bore | 2.1/8' (58) | 2.1/8' (58) | 2.1/8' (58) | 2.1/8' (58) | 2.1/8' (58) |
| Lead screw | 4 TPI | 4 TPI | 4 TPI | 4 TPI | 4 TPI |
| Power Required (Phase 440v) | 2 H.P | 2 H.P | 2 H.P | 3 HP | 3 HP |
| V-belt / flat belt | C-72/2'x 78' | C-72/2'x 78' | C-72/2'x 78' | C-72/2'x 78' | C-72/2'x 78' |
| RPM can be obtained low/high | 25 / 450 | 25 / 450 | 25 / 450 | 25 / 450 | 25 / 450 |
| Overall Dimen. LxWxH | 6'x3.1/2'x4.1/2' | 8'x3.1/2'x4.1/2' | 8'x3.1/2'x4.1/2' | 11'x3.1/2'x4.1/2' | 13'x3.1/2'x4.1/2' |
STANDARD ACCESSORIES:
- Chuck plate, Face plate, Change gear set (inch & mm), toolpost key, 2 nos dead centres, 1 nos centre adptors.
ALSO AVAILABLE AT EXTRA COST:
- More centre Height, V-belt Driven, Flame Hardned bed
