Mini Arc Welder
Product Details:
X
Product Description
Mini Arc Welder
Owing to our rich industry experience, we are engaged in offering our clients an astonishing assortment of Mini Arc Welder. This welder is fabricated as per the defined industry standards using superlative grade raw materials that are sourced from the trustworthy vendors of the market. This Mini Arc Welder is highly acclaimed for its features like reliable performance, compact design, precision engineering & durable finish standards and is offered in diverse specifications as per the requirements of our clients.
Design Features
- Modern Looks, novel design concepts.
- Epoxy powder coated body.
- Coil varnishing by vacuum pressurised impregnating varnishing system.
Specifications
|
Particulars |
Unit |
Mini Welders |
||
|
Model |
|
RM 15 |
RM 20 |
RM 25 |
|
Input Supply |
Volts |
230/415 |
230/415 |
230/415 |
|
Phase |
|
1/2m |
1/2m |
1/2m |
|
Frequency |
Hz's |
50 |
50 |
50 |
|
Open Circuit Voltage (OCV) |
Volts |
50 |
50 |
50 |
|
Welding Current Range |
Amps. |
45-150 |
50-200 |
50-250 |
|
Max. Continuous Hand Welding Current at 60% Duty Cycle |
Amps. |
120 |
160 |
200 |
|
Welding Electrode Size Min. Max. |
MM MM |
1.6 3.15 |
1.6 4 |
1.6 5 |
|
Cooling |
Natural Air |
|||
|
Approx Dimensions |
MM |
L-590 W-365 H-445 |
L-605 W-440 H-480 |
L-605 W-440 H-480 |
|
Approx Weight |
Kgs. |
44 |
54 |
64 |
Note: Due to policy of continuous improvements, we reserve the right to modify the equipments and change specifications without prior notice.
